Orange Pi 5B

RK3588S with eMMC onboard

RK3588S 8-core 64-bit, 8nm LP

6 TOPS NPU, INT4 / INT8 / INT16

Arm Mali-G610 MP4 GPU

4GB / 8GB / 16GB LPDDR4/4X

Up to 256GB onboard eMMC

HDMI 2.1, up to 8K@60Hz

Gigabit Ethernet

Wi-Fi 6 + BT 5.3, BLE

USB 3.1, 2 × USB 2.0, Type-C

RK3588S, eight cores on an 8nm LP process

Four Cortex-A76 cores at 2.4GHz alongside four Cortex-A55 cores at 1.8GHz, in a big.LITTLE arrangement on an 8nm low-power process. It is faster and draws less than the generation before it, which is what makes it viable as an always-on board.

6 TOPS of NPU with mixed precision

The built-in AI accelerator reaches 6 TOPS and supports INT4, INT8 and INT16 in mixed operation, so a quantised model can trade precision for throughput where the workload allows it.

Up to 256GB of onboard eMMC

This is what separates the 5B from the plain Orange Pi 5: eMMC is soldered on rather than sitting in a socket, in 32GB, 64GB, 128GB or 256GB. No card to work loose, and far steadier than microSD under long-running writes.

Wi-Fi 6 and Bluetooth 5.3 with BLE

A 2.4G/5G dual-band Wi-Fi 6 and Bluetooth 5.3 module is onboard, Wi-Fi over PCIe and Bluetooth over PCM and UART. No USB dongle taking up a port, and a steadier signal than the add-on modules it replaces.

8K video codec and multi-screen output

HDMI 2.1 carries up to 8K@60Hz, DisplayPort 1.4 over USB-C reaches 8K@30Hz, and two MIPI D-PHY TX 4-lane outputs run up to 4K@60Hz — enough for a multi-screen wall. Three MIPI camera inputs go the other way.

Rich interfaces, easy to expand

MIPI D-PHY and MIPI CSI, USB 3.1 and USB 2.0, Type-C, HDMI 2.1, Gigabit Ethernet, a 26-pin header for UART, PWM, I2C, SPI, CAN and GPIO, and a 3-pin debug serial port.

Available now in Pakistan

In stock

8GB RAM + 64GB eMMC

The everyday configuration — comfortable for desktop use, camera work and most teaching benches.

In stock

16GB RAM + 128GB eMMC

Headroom for larger models, multi-camera pipelines and anything that keeps a lot resident.

Other RAM and eMMC combinations are available to order — talk to us about lead times.

About the board

Orange Pi 5B is built on the Rockchip RK3588S, an 8-core 64-bit SoC on an 8nm LP process, with four Cortex-A76 cores at 2.4GHz and four Cortex-A55 cores at 1.8GHz, an Arm Mali-G610 MP4 GPU and a 6 TOPS NPU supporting INT4, INT8 and INT16 mixed operation.

The board carries 4GB, 8GB or 16GB of LPDDR4/4X and soldered eMMC from 32GB up to 256GB, plus a MicroSD slot. Connectivity is HDMI 2.1 to 8K@60Hz, DisplayPort 1.4 over Type-C, dual MIPI D-PHY TX outputs, three MIPI camera inputs, Gigabit Ethernet, USB 3.1 and USB 2.0, and an onboard Wi-Fi 6 + Bluetooth 5.3 module.

It runs Orange Pi OS in both Droid and Arch builds, Debian 11, Ubuntu 22.04 and 20.04, and Android 12. We hold it in local stock in Pakistan with warranty and setup support.

Hardware specification

SoC	Rockchip RK3588S (8nm LP process)
CPU	• 8-core 64-bit processor • big.LITTLE architecture: 4 × Cortex-A76 and 4 × Cortex-A55 • Big core cluster 2.4GHz, little core cluster 1.8GHz
GPU	• Arm Mali-G610 MP4 • OpenGL ES 1.1/2.0/3.2, OpenCL 2.2 and Vulkan 1.2 • 3D graphics engine and 2D graphics engine
NPU	Built-in AI accelerator up to 6 TOPS, supports INT4 / INT8 / INT16 mixed operation
PMU	RK806-1
RAM	4GB / 8GB / 16GB (LPDDR4/4X)
Memory	• 32GB / 64GB / 128GB / 256GB eMMC • MicroSD (TF) card slot
USB	• 1 × USB 3.0 • 2 × USB 2.0 • 1 × Type-C (USB 3.1)
Video output	• HDMI 2.1, up to 8K@60Hz • DP 1.4 (DisplayPort), up to 8K@30Hz • 2 × MIPI D-PHY TX 4-lane, configurable up to 4K@60Hz
Camera	• MIPI CSI 4-lane • 2 × MIPI D-PHY RX 4-lane
Audio	• CODEC: ES8388 • 3.5mm headphone jack audio input / output • Onboard MIC input • HDMI 2.1 eARC
Ethernet	10 / 100 / 1000Mbps Ethernet
Expansion port	26-pin dual-row pin header, supporting DC 5V and 3.3V power output and configurable for UART, PWM, I2C, SPI, CAN and GPIO interfaces
Wi-Fi + BT module	Onboard Wi-Fi 6 + BT 5.3 module — Wi-Fi 6 over PCIe, Bluetooth over PCM + UART
Button	1 × MaskROM key, 1 × recovery key, 1 × on/off key
Power source	Type-C power supply, 5V@4A
LED	Power indicator red, status indicator green
Debugging	3-pin debug serial port (UART)
Supported OS	Orange Pi OS (Droid), Orange Pi OS (Arch), Orange Pi OS (OH), Debian 11, Ubuntu 22.04, Ubuntu 20.04, Android 12
Product size	62mm × 100mm
Weight	52g

Note

Product batches and supply change in real time, so the specification above may be revised. Please confirm the exact RAM and eMMC configuration with us before ordering.
